A pencil load cell is a small, cylindrical force sensor used to measure tension or compression in tight spaces. It gets its name from its slim, pencil-like shape. Made of durable materials like stainless steel, it uses strain gauges to convert force into an electrical signal. Commonly used in robotics, medical devices, and precision testing.

Rated load ( kg)– 10 ,20 ,30

Wiring schematic diagram:

Red: Input ( ＋ ) White: Output ( － )
Black: Input ( － ) Green: Output ( ＋ )

Notes：It used 4-core shielded cable(φ5×3000mm)
